From Speed Control to Energy Efficiency: Understanding HIMEL VSD X Series

The Himel VSD X Series is Himel’s variable speed drive (VSD) platform for three-phase 380–480 V motors, split into the HAVXH range for general and high-performance machinery (0.4–160 kW) and the HAVXP range for fans and pumps (0.75–185 kW). It saves energy by slowing motors to match real demand instead of throttling flow with valves […]

11 min read By the Trans-Digi Global team

The Himel VSD X Series is Himel’s variable speed drive (VSD) platform for three-phase 380–480 V motors, split into the HAVXH range for general and high-performance machinery (0.4–160 kW) and the HAVXP range for fans and pumps (0.75–185 kW). It saves energy by slowing motors to match real demand instead of throttling flow with valves or dampers, and on centrifugal pumps and fans even a 20% speed reduction can cut input power by roughly half.

In this article

This guide explains how the X Series controls a motor, where the savings actually come from, which model fits which job, and what to check before you order one for a Singapore project. It draws on the Himel X Series catalogue, Singapore government guidance on motor systems, and what we see when we test and commission drives on site.

What a variable speed drive does

A variable speed drive sits between the supply and an AC induction motor. It changes the frequency and voltage reaching the motor, and so changes the motor’s speed. A motor wired straight to the mains runs at one fixed speed, so any reduction in flow has to be made mechanically, usually with a valve or damper that burns off the surplus energy.

According to the NEA’s Motor Driven Systems reference manual for the Singapore Certified Energy Manager programme, motor systems are generally designed for maximum load but run at full capacity only for short periods, which leaves many systems running inefficiently for long periods. Matching speed to load is the fix.

How the X Series converts power

Like most modern AC drives, the X Series works in three stages:

  • Rectifier: converts the incoming AC supply into DC.
  • DC bus: smooths and stores that DC. The X Series catalogue lists a built-in DC reactor and states that input current distortion (THDi) can reach under 35%.
  • Inverter: switches the DC back into AC at whatever frequency the motor needs, from 0 to 599 Hz on the X Series.

The output frequency sets the motor speed. That speed reference can come from the keypad, a 0–10 V or 0–20 mA analogue signal, digital inputs, or a fieldbus command from a PLC or building management system (BMS).

Where the energy savings come from

Fans and centrifugal pumps are “variable torque” loads. Their flow follows speed, but the power they need follows the cube of speed. The US Department of Energy’s Adjustable Speed Drive tip sheet puts it simply: reducing rotating equipment speed by 20% can reduce input power requirements by approximately 50%.

Fan or pump speedFlow (approx.)Shaft power (ideal cube law)
100%100%100%
90%90%73%
80%80%51%
70%70%34%
50%50%12.5%

Real systems fall short of the ideal curve because of drive and motor losses and, in pumping, static head. The Hydraulic Institute and Europump guide Variable Speed Pumping reports savings of 30% to 50% in many rotodynamic pump installations after VSDs were fitted, and notes that the ratio of static to friction head decides how much a given system can save.

A worked example in Singapore dollars

Take a 15 kW air-handling unit fan that runs 12 hours a day, every day, and can run at 80% speed for most of that time without affecting comfort:

  1. At full speed the fan draws about 15 kW. At 80% speed the cube law gives 15 × 0.8³ ≈ 7.7 kW.
  2. Allowing roughly 95% drive efficiency at that load (in line with the part-load figures in the DOE tip sheet), input is about 8.1 kW.
  3. The saving is about 6.9 kW × 4,380 hours ≈ 30,300 kWh a year.
  4. At SP Group’s regulated tariff of 28.59 cents/kWh before GST for October–December 2026, that is roughly S$8,700 a year.

The drive’s own losses matter too. IEC 61800-9-2 defines IE efficiency classes for drive modules and IES classes for complete motor-drive systems, giving a common basis for comparing losses. Your own figure will depend on your tariff, duty cycle and how the system is controlled today. A pump that already runs near full load all day will save little; the DOE tip sheet is clear that drives do not save energy on equipment that operates close to fully loaded most of the time.

Savings beyond the electricity bill

Ramped starts and stops reduce inrush current and mechanical shock on belts, couplings and bearings. The Variable Speed Pumping guide notes that hydraulic forces on a pump impeller fall roughly with the square of speed, so running slower extends bearing and seal life and lowers vibration and noise, provided the pump stays within its allowable operating range.

HAVXH vs HAVXP: choosing the right X Series model

The two X Series ranges share a platform but are tuned for different jobs. The figures below are from the Himel X Series catalogue.

FeatureHAVXH (general purpose)HAVXP (fans and pumps)
Power range0.4–160 kW0.75–185 kW
Supply3-phase 380–480 V (−15%/+10%)3-phase 380–480 V (−15%/+10%)
Overload, normal duty120% for 1 min, 150% for 3 s120% for 1 min, 150% for 3 s
Overload, heavy duty150% for 1 min, 180% for 3 sNot listed
Motor controlV/F, sensorless vector (SVC), closed-loop vector (FVC)V/F, SVC
Speed accuracy±1% V/F, ±0.5% SVC, ±0.02% FVC±0.5% SVC
Typical usesConveyors, machine tools, extruders, master–slave drive trainsPumps, fans, cooling towers, chillers, ventilation
Application functionsPosition, tension and torque control; master–slavePID with sleep mode, multi-pump control, pump cleaning, frost protection

For building services the HAVXP is usually the natural fit. Its multi-pump function can run up to 8 pumps from 8 drives in master–slave mode, or up to 4 pumps from a single drive with fixed-speed staging, with first-in-first-out or first-in-last-out stop order and automatic duty rotation. PID with sleep mode lets a booster set idle at low demand and wake when pressure falls below a set deviation.

For machinery with heavy starting loads or tight speed control, the HAVXH’s heavy-duty rating and closed-loop vector control with an encoder are the deciding features.

Communication and integration

The X Series has RS485 Modbus RTU built in, with option cards for Modbus TCP, Profibus DP, CANopen, PROFINET and EtherCAT, and BACnet MS/TP for building automation. Himel’s X-Studio PC software handles online monitoring, offline configuration, parameter comparison, an oscilloscope and fault-code diagnosis.

Integration matters more on replacement jobs than on new builds. When we replaced around 40 ventilation-fan VSDs at Republic Polytechnic and around 30 at Singapore Polytechnic, the new drives had to be configured to work with each campus’s existing control system. That is why we confirm the control interface, not just the kW rating, before quoting.

Where the X Series fits in Singapore buildings and plants

  • Building services: air-handling units, cooling tower fans, chilled-water and condenser-water pumps.
  • Water and pumping: booster sets, transfer pumps and circulating pumps.
  • Manufacturing: conveyors, mixers, extruders, packaging and woodworking machinery.
  • Ventilation: industrial fans, dust extraction and drying.

Motors matter at national scale: the IEA 4E Electric Motor Systems Platform reports that motor systems used 53% of global electricity in 2023, including 36% of electricity in buildings. Singapore’s motor efficiency rules make drive selection part of a wider picture. Since 1 October 2018, Minimum Energy Performance Standards for motors have required IE3 efficiency for common three-phase induction motors from 0.75 kW to 375 kW. NEA noted that motors accounted for about 80% of the electricity used in 2015 by companies regulated under the Energy Conservation Act. An efficient motor running at fixed speed against a throttled valve still wastes energy, so the drive and the motor should be considered together.

Harmonics: a specification point worth checking

Every VSD draws non-sinusoidal current from the supply. Many Singapore project specifications set a THDi limit, often with reference to IEEE 519, the standard for harmonic control in electric power systems. The X Series catalogue states THDi can reach under 35% with its built-in DC reactor.

That threshold is familiar to us. On the ST Aerospace aviation centre at Seletar Aerospace Park, the specification required less than 35% THDi, and we measured and monitored the actual harmonic level of every installed drive during testing and commissioning before handover. If your consultant has set a harmonic limit, tell us at quotation stage so the drive, reactor and measurement plan are agreed early.

What to check before you buy a Himel X Series VSD in Singapore

  1. Motor nameplate data: rated power, voltage, full-load current and frequency.
  2. Load type: variable torque (fans, centrifugal pumps) points to HAVXP; constant torque or high starting torque points to HAVXH heavy duty.
  3. Duty cycle: how often the motor starts, stops, reverses or brakes. Check whether the chosen frame size includes a braking unit or needs one added.
  4. Environment: the X Series runs at full rating from −10 °C to 40 °C and derates between 40 °C and 50 °C, at up to 1,000 m altitude. Plant rooms and rooftop panels in Singapore can exceed 40 °C, so check panel ventilation.
  5. Control and communication: I/O count, fieldbus protocol and BMS points.
  6. Electrical installation: cable length to the motor, harmonic limits and any filter requirement. NEA’s reference manual advises not exceeding the manufacturer’s maximum drive-to-motor cable length.
  7. Existing motors: on retrofit jobs, confirm the motor’s condition and insulation. On our Singapore EXPO project, replacement drives had to start and run motors that had been in service for more than ten years.

How Trans-Digi Global supports X Series projects

We are a Singapore-based supplier of drives, soft starters and low-voltage protection, and an authorised partner for Himel. Our services cover product selection and sizing, installation and panel integration, and testing and commissioning, including parameter setting, PID and setpoint configuration, pump cascade and sleep/wake set-up, and BMS interface checks, followed by handover records.

Our project references include more than 100 Himel VSDs for fire pump systems across HDB estates under four Town Councils, 33 drives at Seletar Mall and HVAC drives at a semiconductor plant. If you are weighing the X Series against the Himel Smart Pump Series for a pump-only duty, we will explain which suits the job and why.

For background reading, see how variable speed drives improve motor efficiency and reducing energy waste in pump systems.

Related reading: choosing a VSD for commercial HVAC and cooling towers.

Frequently asked questions about the Himel VSD X Series

What is the Himel VSD X Series?

It is Himel’s three-phase 380–480 V drive platform, made up of the HAVXH range (0.4–160 kW) for general and high-performance machinery and the HAVXP range (0.75–185 kW) for fans and pumps.

How much energy can a VSD save on a fan or pump?

On centrifugal fans and pumps, power falls roughly with the cube of speed, so a 20% speed cut can reduce input power by about half. Pump installations retrofitted with VSDs have reported 30–50% savings, but results depend on the duty cycle and static head.

Should I choose the HAVXH or the HAVXP?

Choose the HAVXP for pumps, fans and HVAC, where its PID, sleep mode and multi-pump functions apply. Choose the HAVXH for conveyors, extruders and machinery that need heavy-duty overload or closed-loop vector control.

Does the X Series work with a building management system?

Yes. Modbus RTU is built in, and option cards add BACnet MS/TP, Modbus TCP, PROFINET, Profibus DP, CANopen and EtherCAT. Confirm the protocol and points list before ordering.

Can I fit an X Series drive to an existing motor?

Usually, yes, but check the motor’s rating, insulation condition and cable length first. We assess these during selection and verify operation during commissioning.

Can I buy a Himel X Series VSD in Singapore?

Yes. Send Trans-Digi Global your motor rating, voltage, application and quantity through our contact page and we will confirm the model, check stock and quote.
